Automatic Slab Edge Trimming Machine

Product Description

Automatic Edge Trimming Machine is a multi-blade saw machine for cutting the edge of the slab. This machine has two parts, one part of edge trimming of slabs in cross direction, another part for edge cutting in the vertical direction. Both two machines are multi-blade design. They can cut a long size slab into many cuts to tile automatically. Big size slabs go in the cross cutter machine and out from another side. All these are automatic, compare with bridge-type stone cutting machine. This machine is more quickly speed for cutting the slab in the same size. But the stone bridge cutting machine would be a better choice if you want to cut the slab into various kinds of sizes. An automatic slab edge trimming machine is an ideal machine for cutting slabs into small pieces, these small tiles are very suitable for the project. At the end of the machine part, you will receive final products. We suggest customers buy a vacuum slab loading machine to load and unloading the final products.

In this case, you could make all the steps of the job with fully automatic. Before we have talked about the installation of a stone cutting machine, here we will share more of this information on how to install the slab edge trimming machine. The assembling requirement of the pulley is that the axes of two pulleys must be parallel, and the center of the groove should be positive. If the pulley is offset, the pulley tension will be uneven, resulting in belt slippage and accelerated wear. At the same time, the triangular belt should be selected before assembly, and the length should be the same to prevent vibration in transmission.

Before assembling, bearings should be cleaned and rust-proof paint should be washed before assembling; when cleaning, attention should be paid to checking whether the raceway and rolling body are rusted and the rotation is flexible; when assembling bearings, a layer of lubricant should be applied on the surface of the fittings; when assembling, if the pressure difference is too large, the assembly should be stopped for inspection; when assembling bearings, the non-model end should be inward, in the direction of the shoulder; when assembling bearings, the assembly of bearings The magnitude, direction and position of the additional force should be appropriate. The rolling body of the raceway should not be subjected to force. The raceway should be beaten symmetrically and evenly, and the end face should be perpendicular to the axis, so as to prevent the installation from tilting.

Product Details

Product Specifications
